Characteristics:

• Cast iron firebox, hearth and brazier
• Shell and tube heat exchanger
• Removable ash compartment
• High capacity pellet storage tank (~ 27 kg)
• Front room ventilation with 2 dedicated motors and Pro Air Setup function
• Double ducting with two dedicated motors up to 8 meters, thermostatically controlled and excludable + AIR ZONE CONTROL
• Possibility of exit for ducting (Ø80 mm): rear
• Wide view of the flame
• Handle with ergonomic grip
• Smoke exhaust outlet options: rear in line, upper in line
• Removable hearth from authorized service
• Watertight tank
• FPC Plus function
• Ceramic spark plug
• Integrated Wi-Fi (“Total Control 3.0” App)

3.8-12.0 kW Nominal thermal power

344 m3 heatable

TECHNICAL DATA:

• Dimensions (LxHxD) 525x1080x652 mm
• Hourly consumption 0.9 - 2.7 kg/h
• Total tank capacity 27 kg
• Flue pipe diameter (Ø) 80 mm P/S
• Yield 94 - 93%
• Net Weight 172 kg
• DM186 5-star Environmental Certification
• Energy Class A+
• Nominal thermal power 3.8 - 12 kW
• m³ heatable 344 m³ (*)
• (*) - The data is indicative and refers to the requirement of 30 kcal/hx m³
