Comfort throughout the home
The Cadel Cristal 7 UP is designed to provide uniform heating thanks to ducting , which allows hot air to be distributed even to adjacent rooms. It is the ideal solution for those who want uniform comfort without installing multiple heat generators.
Easy installation
The upper flue outlet allows you to reduce the rear bulk of the stove, facilitating installation close to the wall and improving the aesthetics of the room.
Smart technology
With built-in Wi-Fi and Bluetooth , you can:
- turn the stove on and off remotely;
- regulate the temperature;
- schedule time slots and days of operation;
- monitor the status of the stove via the App.
Energy saving
The Cristal 7 UP is designed to offer:
- high performance;
- low fuel consumption;
- low emissions;
- long battery life;
- constant comfort.
Quality materials
Cadel construction quality guarantees reliability and durability thanks to:
- cast iron brazier;
- high efficiency combustion chamber;
- advanced electronics;
- quality components.
Ideal for
✔ apartments
✔ independent homes
✔ open space
✔ well-insulated houses
✔ renovations
✔ second homes
Main features
- Rated power: 7 kW
- Hot air ducting
- Upper smoke outlet (Top)
- Built-in Wi-Fi
- Built-in Bluetooth
- Airtight chamber
- Cast iron brazier
- Daily and weekly programming
- High yield
- Reduced consumption
- 5 Star Environmental Class
- Ecodesign Certification
- Room thermostat provision
- Remote control (optional)
Advantages
- Simplified installation thanks to the upper flue outlet.
- Heat distribution in multiple rooms.
- Remote control via smartphone.
- High energy efficiency.
- Reduction of pellet consumption.
- Reliable and quiet operation.
- Sturdy and durable materials.
- Excellent value for money.
Technical Data Sheet – Cadel Cristal 7 UP Pellet Stove
| Characteristic | Value |
|---|
| Brand |
Cadel |
| Model |
Crystal 7 UP |
| Typology |
Ductable ventilated pellet stove |
| Rated power |
7 kW |
| Reduced power |
about 2.5 kW |
| Power released to the environment |
up to 7 kW |
| Heatable volume |
up to 200 m³* |
| Heatable surface |
up to 75 m²* |
| Performance |
over 90% |
| Energy class |
A+ |
| Environmental class |
⭐⭐⭐⭐⭐ (5 Stars) |
| Certification |
Ecodesign 2022 |
| Fuel |
Pellets Ø 6 mm |
| Tank capacity |
15 kg |
| Pellet consumption |
0.6 – 1.7 kg/h |
| Autonomy |
up to 25 hours |
| Channeling |
Yes |
| Front ventilation |
Yes |
| Built-in Wi-Fi |
Yes |
| Built-in Bluetooth |
Yes |
| Management App |
Yes |
| Daily and weekly programming |
Yes |
| Remote control |
Optional |
| Airtight chamber |
Yes |
| Brazier |
Cast iron |
| Smoke exhaust |
Ø 80 mm |
| Combustion air intake |
Ø 60 mm |
| Smoke outlet |
Superior (Top) |
| Provision for external thermostat |
Yes |
| Power supply |
230 V – 50 Hz |
| Available colors |
White, Anthracite, Bordeaux Red (according to range) |
* The heatable volume and surface area may vary depending on the insulation of the home, the height of the rooms and the climate zone.
FAQ
What is the difference between Cristal 7 and Cristal 7 UP?
The Cristal 7 UP features a top flue outlet , making it easier to install and improving its aesthetic integration into any space. It also features ducting , allowing it to heat adjacent rooms as well.
Can the Cristal 7 UP heat multiple rooms?
Yes. Thanks to the ducting system, it is possible to distribute hot air to different rooms.
Is it possible to control the stove from a smartphone?
Yes, thanks to the built-in Wi-Fi and Bluetooth.
Is it an airtight stove?
Yes, it is equipped with a sealed chamber, also ideal for high energy efficiency homes.
Is it compatible with the Thermal Account?
Yes, as long as the installation complies with the requirements set by current legislation.
