Guenda Idro 5.0 La Nordica Extraflame hermetic ventilated pellet stove
Guenda Hydro 5.0
Ventilated pellet stove
Characteristics :
• Self-cleaning brazier with brushless motor
• Ceramic spark plug for quick ignition
• Front room ventilation with dedicated motor, excludable
• Brushless pellet loading motor
• Circulator with PWM control
• Watertight tank
• Air vent
• Possibility of exit for smoke exhaust: rear
• Wide view of the flame
• Pressure transducer with display
• Combustion chamber in high thickness steel
• Handle with ergonomic grip
• Cast iron fire door and brazier
• Probe in combustion chamber
• Shell and tube heat exchanger (manual cleaning)
• Thermal and water pressure safety devices
• Expansion vessel
• 3 bar safety valve
• Removable ash drawer
• FPC Plus function
5.0-16.7 kW Nominal thermal power
14.0 kW-H 2 O Power output to water
479 m 3 m³ heatable
Yield 92.5 - 92.4 %
Hourly consumption 1.1 - 3.7 kg/h
Dimensions (WxHxD) 576 x 1157 x 621 mm
Net Weight 210 kg
Smoke exhaust diameter (Ø)100 mm P
Total tank capacity ~30 kg
Energy Class A+
Environmental Certification DM186 5 STARS
