Characteristics:

• New "5-star" brazier
• Combustion chamber made of high thickness steel
• Cast iron fire pit and brazier
• Watertight tank
• Removable ash drawer
• Excludable front ventilation
• Ceramic glow plug for quick ignition
• Circulator with PWM control
• FPC – Innovative adaptive system for regulating and maintaining constant combustion air over time
• PRO AIR SETUP. Choice between: Quiet/Regular/Boost
• Anti-condensation management
• Easy Setup
• Easy Control
• Self-Control
• Home automation integration with "Alexa" (Amazon). NB Only in combination with the optional "Grey Label" WiFi Module and use of the TotalControl 3.0 App. "Alexa" (Amazon) service and peripheral not included.

TECHNICAL DATA:

• Dimensions (LxHxD) 550x1039x601 mm
• Hourly consumption 4.2 - 14.8 kg/h
• Total tank capacity ~ 20 kg
• Flue pipe diameter (Ø) 80 mm
• Yield 94 - 93%
• Power output to water 3 - 11 kW-H₂O
• Net Weight 180 kg
• DM186 5-star Environmental Certification
• Energy Class A+
• Nominal thermal power 4.2 - 14.8 kW
• m³ heatable 424 m³ (*)
• (*) - The data is indicative and refers to the requirement of 30 kcal/hx m³
