Characteristics:

• Steel and cast iron fireplace
• Doors, facade and frame in enamelled cast iron
• Polished cast iron plate and rims
• Removable ash drawer
• Adjustable primary and secondary air for better combustion management
• Low-emission post-combustion system
• Ceramic glass
• Firewood drawer
• Provision for DSA safety device (optional DSA valve)
• Upper central or rear flue outlet

16.8 kW Nominal thermal power

10.3 kW Power output to water

482 m³ heatable m³

Technical data:

• Dimensions (WxHxD) 1075x861x696 mm
• Hourly consumption 4.6 kg/h
• Flue pipe diameter (Ø) 160 mm
• Yield 86%
• Power output to water 10.3 kW-H₂O
• Net Weight 286 kg
• DM186 4-star Environmental Certification
• Energy Class A+
• Nominal thermal power 16.8 kW
• m³ heatable 482 m³ (*)
• Product certified according to EN 16510-2-1
